Elkay LK4420BF1U Outdoor ezH2O Bottle Filling Station with Drinking Fountain



Part Number: #89841
Manufacturer: Elkay Manufacturing
Mfg Number: LK4420BF1U
Installation: Outdoor Bi-Level Pedestal ezH2O Bottle Filling Station and Drinking Fountain
ADA Compliant: Yes
Finish: Tubular steel with weather resistant textured finish (tubular steel undergoes E-Coat immersion process)
Filter Included: Non-Filtered
Vandal Resistant: Yes
Operation: Manually Operated Bottle Filler
Shipping Weight: 190 lbs

This Outdoor Bi-Level Pedestal ezH2O Bottle Filling Station and Drinking Fountain by Elkay maintains a year-round beauty with minimum maintenance and protects against corrosion. Patrons can get a quick drink of water from the ADA Compliant drinking fountain, or also fill up a reusable water bottle with the bottle filler station. Bottle filling stations promote sustainability and reduce plastic waste by encouraging reusable plastic bottles. This unit is ideal in most any outdoor settings. This unit is also a non-refrigerated unit and requires no electrical power source.

Specify color when placing your order, refer to the color chart above or in the options section.

• Bottle Filler provides a quick fill at 1.0 GPM. Laminar flow provides a clean fill with minimal splash and easy maintenance.
• Vandal-resistant bubbler is one-piece, heavy duty construction. This unit has integral hood guard design to prevent contamination from other users, airborne deposits, and tampering.
• Contour-formed stainless steel design with rounded edges reduces splatter, insures proper drainage and prevents standing water.
• Self-closing, vandal-resistant push button does not require grasping or twisting.
• Easy to Clean in-line strainer screen traps particles of 140 microns or larger before they enter the waterway.
• Inlet: 3/8" O.D. Tubing; Outlet: 1-1/2" tube outlet for 1-1/2" slip joint connection.
• Access Panels are made of heavy-gauge steel with vandal resistant screws. Provides access for easy hook-up of all plumbing connections.
• Built in the USA

• Spec Sheet (PDF)
